AGRICULTURE, CONSTRUCTION, LANDSCAPING, 3PT BOX BLADES

This heavy-duty, rear-mount box blade offers you perfect compatibility for leveling, backfilling, grading, and moving a variety of material. Designed & made in the USA.

• The box blade grades, levels, and backfills on uneven roads, driveways, gardens, or areas around barns and buildings.
• Collects gravel to level ruts and potholes.
• Cleans up and levels mulch piles.
• Clears material out of barns.
• Creates gravel roads or driveways.

Four-Hole Ripper Shanks - The ripper shanks adjust up or down to vary the cutting depth for mixing loose soil or tearing through compacted soil or rocks.

Replaceable Ripper Shanks & Cutting Edges - The ripper shanks and blades can be replaced to extend the life of your attachment.

Front and Back Blades - Cutting edges on both the back and front allow you to work forward or reverse so you can get more done in less time.

Reversible Steel Cutting Edges - Simply flip the blade over to get a fresh cut and double the life.

Width - Available in 48-inch, 60-inch, and 72-inch blade widths.

Category 1, 3-Point Hitch - A 3-point hitch is used to attach your rear-mounted box blade implement. An adjustable top link is centered above two lower link arms, comprising the three points. The box blade quickly and easily fits with connecting pins at each point.

Corrosion-Resistant, Powder-Coat Finish - The box blade features a durable, corrosion-resistant powder-coat finish that protects the attachment in the elements.

How It Works - The box blade implement does not require power-take-off (PTO). Simply attach it to the 3-point hitch and get started. The implement can be raised or lowered to control the height of the cutting edge. Lower the cutting edge to cut, and raise it to dump and spread the material.

Includes a 12-month warranty

Tractor Horsepower - 18-30 (48"), 26-65 (60"), 35-65 (72")

Operating Weight - 245 lbs (48"), 395 lbs (60"), 445 lbs (72")

Length - 28 in (48"), 31 in (60"), 31 in (72")

Width - 49.5 in (48"), 61.5 in (60"), 73.5 in (72")

Height - 32 in (48"), 33 in (60"), 33 in (72")

Ripper Shanks - 4 (48"), 5 (60"), 6 (72")

Steel Thickness - 3/8" (side plates), 3/16" or 7 ga (back plate)
